| Код | Кол-во | Примечание |
|---|---|---|
| 1 headlight with dipped beam and main beam | ||
|
001
|
LI,RRV
|
|
| 2 Кабельный жгут | ||
|
001
|
LI LI
|
|
| 3 corrugated protective tube | ||
|
PM
|
D=10mm
|
|
| 4 cable gland | ||
|
002
|
|
|
| 5 Уплотнительное кольцо | ||
|
002
|
S=12
|
|
| 6 Клипсы стопорные | ||
|
002
|
D1=10.6,S=2
|
|
| 7 Уплотнительная заглушка | ||
|
002
|
38X45X58
|
|
| 8 Уплотнительная заглушка | ||
|
002
|
|
|
| 9 headlight with dipped beam and main beam | ||
|
001
|
RE,RRV
|
|
| 10 Кабельный жгут | ||
|
001
|
RE RE
|
|
| 11 halogen bulb H4 | ||
|
002
|
24V75/70W
|
|
| 12 bulb Ba9s | ||
|
002
|
24V4W
|
|
| 13 bulb Ba15s | ||
|
002
|
24V,21W
|
|
| 14 Задний фонарь | ||
|
001
|
LI+RE
|
|
| 15 Задний фонарь | ||
|
001
|
|
|
| 16 bulb Ba15s | ||
|
008
|
24V,21W
|
|
| 17 bulb Ba15s | ||
|
004
|
24V,10W
|
|
| 18 wiring harness, rear light | ||
|
001
|
LI
|
|
| 19 Уплотнительная заглушка | ||
|
001
|
22 X 3
|
|
| 20 Уплотнительная заглушка | ||
|
001
|
|
|
| 21 wiring harness, rear light | ||
|
001
|
RE
|
|
| 22 Уплотнительная заглушка | ||
|
001
|
22 X 3
|
|
| 23 Уплотнительная заглушка | ||
|
001
|
|
|
| 24 earth clamp | ||
|
001
|
A=70,L=450,D=10
|
|
| 25 Провод батареи | ||
|
001
|
A=70,T=350
|
|
| 26 shrink sleeve | ||
|
PM
|
|
|
| 27 electric wire, single conductor | ||
|
PM
|
A=70
|
|
| 28 shrink sleeve | ||
|
PM
|
|
|
| 29 corrugated protective tube | ||
|
PM
|
D=17mm
|
|
| 30 Закрывающ. кожух | ||
|
001
|
|
|
| 31 L-bracket, 90 degrees | ||
|
001
|
115X35X25
|
|
| 32 hexagon bolt, metric thread | ||
|
004
|
M8X25
|
|
| 33 hexagon nut, metric thread | ||
|
004
|
M8
|
|
| 34 spring washer, arched | ||
|
004
|
M8
|
|
| 35 standard air horn | ||
|
001
|
|
|
| 36 pipe clip for 1 or 2 lines | ||
|
002
|
D=25,D1=6.4
|
|
| 37 bracket, electrical system | ||
|
001
|
|
|
| 38 bracket, electrical system | ||
|
001
|
|
|
| 39 pan head screw | ||
|
002
|
M6X16
|
|
| 40 spring washer, arched | ||
|
002
|
M6
|
|
| 41 bracket, electrical system | ||
|
001
|
|
|
| 42 battery clamp, positive pole | ||
|
001
|
M12
|
|
| 43 plastic clamping strap | ||
|
X
|
L=203,B=3.6mm
|
|
|
X
|
L=188,B=4.8mm
|
|
|
X
|
L=203,B=7.6mm
|
|
| 44 Уплотнительная заглушка | ||
|
X
|
60X6
|
|
| 45 hexagon bolt, metric thread | ||
|
003
|
M6X16
|
|
| 46 trimming section | ||
|
PM
|
9X6mm
|
|
| 47 hexagon nut, metric thread | ||
|
002
|
M6
|
|
| 48 spring washer, arched | ||
|
001
|
M8
|
|
| 49 hexagon nut, metric thread | ||
|
001
|
M8
|
|
| 50 nozzle tip, screen washer | ||
|
002
|
|
|
| 51 headlamp washer pump | ||
|
001
|
|
|
| 52 Уплотнительная заглушка | ||
|
001
|
10X21X15mm
|
|
| 53 3-way coupling | ||
|
001
|
|
|
| 54 hexagon bolt, metric thread | ||
|
002
|
M8X25
|
|
| 55 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 56 spring washer, arched | ||
|
002
|
M8
|
|
| 57 hexagon nut, metric thread | ||
|
003
|
M6
|
|
| 58 spring washer, arched | ||
|
003
|
M6
|
|
| 59 pan head screw | ||
|
008
|
M6X85
|
|
| 60 plain washer, normal | ||
|
008
|
M6
|
|
| 61 Кольцо | ||
|
008
|
|
|
| 62 earth strip | ||
|
001
|
T=250
|
|
| 63 pan head screw | ||
|
002
|
|
|
| 64 plain washer, hard | ||
|
002
|
M4
|
|
| 65 hexagon screw, metric thread | ||
|
004
|
M6X12
|
|
| 66 plain washer, normal | ||
|
008
|
M6
|
|
| 67 hexagon nut, metric thread | ||
|
004
|
M6
|
|
| 68 Электр. штепсель | ||
|
X
|
26X16
|
|
| 69 pipe clip for 1 or 2 lines | ||
|
001
|
D=15,D1=7
|
|
| 70 L-bracket | ||
|
001
|
|
|
| 71 hexagon bolt, metric thread | ||
|
001
|
M10X25 8.8
|
|
| 72 hexagon nut, metric thread | ||
|
002
|
M10
|
|
| 73 plain washer, hard | ||
|
002
|
10.5x21x2mm
|
|
| 74 Уплотнительное кольцо | ||
|
X
|
|
|
| 75 protection cover, battery clamp | ||
|
001
|
|
|
| 76 L-bracket, 90 degrees | ||
|
001
|
25X35X60X3
|
|
| 77 cable gland | ||
|
001
|
M35
|
|
| 78 Уплотнительное кольцо | ||
|
001
|
D1=25.2
|
|
| 79 Переходник | ||
|
001
|
M35X1.75
|
|
| 80 corrugated protective tube | ||
|
001
|
D=17mm
|
|
| 81 chassis wiring harness | ||
|
001
|
|
|
-+
