| Код | Кол-во | Примечание |
|---|---|---|
| 1 plastic clamping strap | ||
|
X
|
L=203,B=7.6mm
|
|
| 2 rectangular fixation plate | ||
|
001
|
|
|
| 3 hexagon screw, metric thread | ||
|
001
|
M8X20 8.8
|
|
| 4 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 5 spring washer, arched | ||
|
002
|
M8
|
|
| 6 pipe clip for 1 or 2 lines | ||
|
001
|
D=44,D1=8.5
|
|
| 7 hose smaller than 16mm | ||
|
PM
|
|
|
|
PM
|
D=10mm,L=100M
|
|
| 8 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 9 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 10 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 12 hexagon bolt, metric thread | ||
|
002
|
M8X25
|
|
| 13 hexagon nut, metric thread | ||
|
004
|
M8
|
|
| 14 spring washer, arched | ||
|
004
|
M8
|
|
| 15 relay valve, service brake | ||
|
001
|
|
|
| 16 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 17 seal ring, part for pipe coupling | ||
|
003
|
|
|
| 18 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 19 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 20 straight reducer, part for pipe coupling | ||
|
001
|
|
|
| 21 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 22 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 23 seal ring, part for pipe coupling | ||
|
001
|
|
|
| 24 hose smaller than 16mm | ||
|
PM
|
D=8,L=10M
|
|
| 25 reinforcement sleeve | ||
|
002
|
8
|
|
| 26 clamp-cutting ring, part for pipe coupling | ||
|
002
|
8
|
|
| 27 union nut, part for pipe coupling | ||
|
002
|
M14X1.5,D=8mm
|
|
| 28 hose smaller than 16mm | ||
|
PM
|
|
|
|
PM
|
D=10mm,L=100M
|
|
| 29 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 30 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 31 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 32 male coupling, part for pipe coupling | ||
|
002
|
|
|
-+
