| Код | Кол-во | Примечание |
|---|---|---|
| 1 gasket, coolant pump | ||
|
001
|
|
|
|
001
|
|
|
| 2 blanking plate, coolant pump | ||
|
001
|
|
|
| 3 gasket, coolant pump | ||
|
001
|
|
|
|
001
|
|
|
| 4 cylinder head screw | ||
|
002
|
|
|
| 5 cylinder head screw with hexagon socket and metric thread | ||
|
004
|
M8 X 50
|
|
| 6 hexagon screw, metric thread | ||
|
003
|
M8X16
|
|
| 7 Вал насоса охлаждающей жидкости | ||
|
001
|
|
|
| 8 coolant pump impeller | ||
|
001
|
|
|
| 9 coolant pump seal ring | ||
|
001
|
19X40X20
|
|
| 10 bearing, coolant pump | ||
|
001
|
|
|
| 12 spring retaining ring for holes | ||
|
001
|
|
|
| 14 drive flange, coolant pump | ||
|
001
|
|
|
| 15 Электр. штепсель | ||
|
X
|
|
|
| 16 Хомут шланга | ||
|
X
|
D=38-50
|
|
| 17 valve seat, thermostat | ||
|
001
|
|
|
| 18 gasket, thermostat housing | ||
|
001
|
|
|
|
001
|
|
|
| 19 stud, metric thread | ||
|
004
|
M8XM8X18
|
|
| 20 spring washer, waved | ||
|
004
|
M8
|
|
| 21 hexagon nut, metric thread | ||
|
004
|
M8
|
|
| 22 thermostat, coolant | ||
|
001
|
|
|
| 23 seal ring between coolant pump and thermostat | ||
|
001
|
57.7X67.5X6.4
|
|
| 24 thermostat cover | ||
|
001
|
|
|
|
001
|
|
|
| 25 hexagon bolt, metric thread | ||
|
002
|
M8X25
|
|
| 26 spring washer, waved | ||
|
004
|
M8
|
|
| 27 gasket, thermostat housing | ||
|
001
|
|
|
| 28 Уплотн. заглушка | ||
|
001
|
M22X1.5X18
|
|
| 29 copper sealing washer | ||
|
001
|
22x29x1.5 mm
|
|
| 30 flange gasket, coolant pipe | ||
|
004
|
|
|
| 31 coolant pipe 02, cylinder head | ||
|
001
|
|
|
| 32 Гибкий шланг | ||
|
001
|
|
|
| 33 Хомут шланга | ||
|
002
|
D=60-80
|
|
| 34 coolant pipe 01, cylinder head | ||
|
001
|
|
|
| 35 hexagon bolt, metric thread | ||
|
008
|
M10X80
|
|
| 36 spring washer, waved | ||
|
008
|
|
|
| 37 Гибкий шланг | ||
|
001
|
|
|
| 38 Хомут шланга | ||
|
002
|
D=60-80
|
|
| 39 hexagon bolt, metric thread | ||
|
002
|
M8X60
|
|
| 40 Коробка термостата | ||
|
001
|
|
|
| 41 Насос охлаждающей жидкости, узел | ||
|
001
|
|
|
-+
