Выбор запчасти
Например
XLRAS47XS5E701948
| Код | Кол-во | Примечание |
|---|---|---|
| 1 bracket, engine lubrication system | ||
|
002
|
|
|
| 2 straight coupling piece | ||
|
001
|
|
|
| 3 Уплотнительное кольцо | ||
|
002
|
D=29.75
|
|
| 4 hexagon bolt, metric thread | ||
|
002
|
M10X60 8.8
|
|
| 5 hexagon bolt, metric thread | ||
|
002
|
M10X25 8.8
|
|
| 6 plain washer, hard | ||
|
004
|
10.5x21x2mm
|
|
| 7 Элем. масл. фильтр | ||
|
001
|
|
|
| 8 copper sealing washer | ||
|
001
|
18.2X23.9X1.5
|
|
| 9 Патрубок | ||
|
001
|
|
|
| 10 Крышка маслоохладителя | ||
|
001
|
|
|
| 11 Уплотнительное кольцо | ||
|
002
|
D=29.75
|
|
| 12 hexagon bolt, metric thread | ||
|
004
|
M10X65
|
|
| 13 plain washer, hard | ||
|
004
|
10.5x21x2mm
|
|
| 14 oil cooler element | ||
|
001
|
|
|
| 15 Уплотнительное кольцо | ||
|
002
|
D=32
|
|
| 16 hexagon bolt, metric thread | ||
|
004
|
M8X40
|
|
| 17 copper washer | ||
|
004
|
|
|
| 18 Крышка маслоохладителя | ||
|
001
|
|
|
| 19 Плоск. уплот. кольцо | ||
|
001
|
|
|
| 20 cylinder head screw with hexagon socket and metric thread | ||
|
014
|
M8X16
|
|
| 21 plain washer, hard | ||
|
014
|
8.4x17x1.6 mm
|
|
| 22 male or female hose nipple | ||
|
001
|
|
|
| 23 Трубка уровнемера | ||
|
001
|
|
|
| 24 clamp-cutting ring, part for pipe coupling | ||
|
001
|
|
|
| 25 union nut, part for pipe coupling | ||
|
001
|
M26X1.5,D=18mm
|
|
| 27 flange bolt, metric thread, smooth | ||
|
001
|
M6X12
|
|
| 30 dipstick, engine | ||
|
001
|
|
|
| 31 Уплотнительное кольцо | ||
|
001
|
|
|
| 32 filler cap, oil filling pipe | ||
|
001
|
|
|
| 33 Трубка заливки масла | ||
|
001
|
|
|
| 34 Плоск. уплот. кольцо | ||
|
001
|
|
|
| 35 hexagon screw, metric thread | ||
|
001
|
M8X20 8.8
|
|
| 36 spring washer, waved | ||
|
004
|
M8
|
|
| 37 Регулирующий клапан | ||
|
001
|
|
|
| 38 Плоск. уплот. кольцо | ||
|
001
|
|
|
| 39 hexagon screw, metric thread | ||
|
001
|
M8X20 8.8
|
|
| 40 spring washer, waved | ||
|
004
|
M8
|
|
| 41 Гибкий шланг | ||
|
001
|
|
|
| 42 Хомут шланга | ||
|
001
|
D=32-44
|
|
| 43 flange gasket | ||
|
002
|
|
|
| 44 Фланец | ||
|
001
|
|
|
| 45 hexagon screw, metric thread | ||
|
001
|
M8X20 8.8
|
|
| 46 connecting bend, lubrication system elements | ||
|
001
|
|
|
| 47 hexagon screw, metric thread | ||
|
001
|
M8X40
|
|
| 48 hexagon bolt, metric thread | ||
|
002
|
M8X55
|
|
| 49 spring washer, waved | ||
|
003
|
M8
|
|
| 56 Трубка охлажд. жидк. | ||
|
001
|
|
|
| 57 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 58 union nut, part for pipe coupling | ||
|
002
|
M26X1.5,D=18mm
|
|
| 59 check nut | ||
|
002
|
M22X1,5
|
|
| 60 male coupling, part for pipe coupling | ||
|
002
|
M22X1.5-M26X1.5
|
|
| 61 sealing plug, fine metric thread | ||
|
001
|
M10X1X11
|
|
| 66 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 67 Сопряжение типа банджо | ||
|
002
|
|
|
| 68 Пустотелый винт | ||
|
002
|
M14X26
|
|
| 69 copper sealing washer | ||
|
002
|
14.2x19.9x1.5mm
|
|
| 70 copper sealing washer | ||
|
002
|
14.2x19.9x1.5mm
|
|
| 71 Уплотн. заглушка | ||
|
002
|
M14X1.5X18
|
|
| 72 engine oil cooler | ||
|
001
|
|
|
| 73 plastic clamping strap | ||
|
001
|
L=188,B=4.8mm
|
|
-+
